Automatic 3/5 gallon mineral/pure water filling mahcine(900 buckets/hours)
Main technical parameters of the device:
18.9 Liters (equal to 5 gallons)
11.3 Liters (equal to 3 gallons)
Bottle’s specification (mm)
Cap’s specification (mm)
Rated input power
Disinfectant washing pump
Pure washing/filling pump
Three phase AC 380V±5% 50Hz
Single phase AC 220V±5% 50Hz
Requirement of air compressor
0.1 M³ 0.17 M³/Min 0.8Mpa/Cm²
Requirement of water supply
The device employs key components of electrical appliances and metal materials manufacturing by name brand factories from home and abroad. Not only is the device provided with the style of original installation from abroad with advanced technology, high automatization, easy operation and reliable performances, but also features with small size, small weight and beautiful appearance, anti-corrodibility, thorough disinfectant, prevention of air polluted effectively and insurance of high quality, which is available for the production of 5 & 3 gallons bottle water filling and applied to the food & drink industry, medical industry and chemical industry widely.
XG-100/J PLC-Controlled Microcomputer Auto Bottle Washer & Filler manufactured by our company, which concentrates the functions of bottle washing, filling and capping with 5 gallons on one set of machine and manufactured with the standard of America Drinking Water Industry Association & with reference to overseas newest type of equipment.
Thebottle entering--> disinfectant swashing--> pure water--> washing--> bottle dropped down--> bottle seated on the bottle pushing supporter--> pure water feeding--> (cap-aligning) cap-covering--> capping--> output of finished water
The complete set of equipment is manufactured by high-tension stainless steel materials and stainless plate steel with precise argon arc, infrequent distortion and fair welding veins;
The conveying component structures with stainless steel to assure normal running of the device under various conditions; Nonmetallic components are manufactured elaborately by wearable materials, such as nontoxic PP plastic, etc;
In order to make the performance of the device more stable, most of conveying electromotor and booster pump are those products that exportation and electrical components are manufactured elaborately by imported series of products or name brand series of products at home.
